Destacar:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Regenerative Heat Exchanger Evaporator Coil, Small Evaporator Coil, Refrigerator Evaporator Coil


Modelo No.:	vela-11	Princípio:	Intercâmbio de calor regenerativo
Estilo:	Tipo de placa	Material:	Aço inoxidável
Diâmetro do tubo de cobre:	Φ7, Φ7.94, Φ9.52	Tipo de tubo:	Tubo interno ranhurado ou liso
Tipo de folha de alumínio:	hidrofílico ou nu	Tipo de barbatana:	aleta de veneziana, aleta plana, aleta corrugada
Arremesso de fin:	Ø7 1.1~1.8mm, Ø7.94 1.4~2.0mm, Ø9.52 1.4~2.3mm	Passo do furo:	20,5x12,7mm, 22x19,05mm, 21x12,7mm, 25,4x22mm
Espessura da barbatana:	0,095~0,2mm	Espaço da aleta:	1.4~2.3 mm
Material do tubo:	Cobre, alumínio	Capacidade de produção:	50000 peças/ano
Código HS:	8419500090

Modelo No.:	vela-11
Princípio:	Intercâmbio de calor regenerativo
Estilo:	Tipo de placa
Material:	Aço inoxidável
Diâmetro do tubo de cobre:	Φ7, Φ7.94, Φ9.52
Tipo de tubo:	Tubo interno ranhurado ou liso
Tipo de folha de alumínio:	hidrofílico ou nu
Tipo de barbatana:	aleta de veneziana, aleta plana, aleta corrugada
Arremesso de fin:	Ø7 1.1~1.8mm, Ø7.94 1.4~2.0mm, Ø9.52 1.4~2.3mm
Passo do furo:	20,5x12,7mm, 22x19,05mm, 21x12,7mm, 25,4x22mm
Espessura da barbatana:	0,095~0,2mm
Espaço da aleta:	1.4~2.3 mm
Material do tubo:	Cobre, alumínio
Capacidade de produção:	50000 peças/ano
Código HS:	8419500090

Small Refrigerator Stainless Steel Evaporator Coil with Regenerative Heat Exchanger

Factory Price Refrigerator Small Condenser Stainless Steel Evaporator Coil

Product Specifications

Material: copper, aluminum, galvanized plate
Copper pipe: diameter Φ7, Φ7.94, Φ9.52, inner grooved or smooth tube
Aluminum foil: hydrophilic or bare
Fin type: louver fin, flat fin, corrugated fin
Pitch of fins: Ø7 1.1~1.8mm, Ø7.94 1.4~2.0mm, Ø9.52 1.4~2.3mm
Pitch of holes and pitch of rows: 20.5x12.7mm, 22x19.05mm, 21x12.7mm, 25.4x22mm equilateral triangle arrangement

Evaporator Specifications

NO	Tube Diameter(mm)	Distance of hole/row(mm)	Fin Style	Fin Space(mm)
1	Φ7	21*12.7	Louvered fin, Plain fin, Sine wave fin	1.4~2.0
2	Φ7	21*18.9	Sine wave fin, Corrugated fin	1.3~1.9
3	Φ7	25*21.65	Louvered fin	1.5~3.8
4	Φ9.52	25.4*22	Louvered fin, Sine wave fin	1.6~6.35
5	Φ9.52	25.4*22	Louverd fin, Plain fin, Sine wave fin	1.6~3.2
6	Φ9.52	25*19	Louverd fin, Plain fin, Sine wave fin	1.4~3.2
7	Φ9.52	25*21.65	Louvered fin, V ripple fin	2.0~3.8
8	Φ9.52	25*25	Plain fin	1.6~3.2
9	Φ9.52	25*21.65	Plain fin	2.0~6.0
10	Φ9.52	25.4*22	Louvered fin, Plain fin, Sine wave fin	1.6~6.35
11	Φ9.52	31.75*27.5	Louvered fin, Plain fin, Sine wave fin	1.6~6.35
12	Φ12.7	31.75*27.5	Plain fin, Sine wave fin, V ripple fin	1.8~6.0
13	Φ12.7	31.75*27.5	Louvered fin, Plain fin, Sine wave fin, V ripple fin	1.7~2.2
14	Φ12.7	31.75*27.5	Corrugated fin	1.6~2.9
15	Φ15.88	38.1*33	Plain fin, Sine wave fin, V ripple fin	2~4

Product Series Comparison

Specification	Series 1	Series 2	Series 3	Series 4
Tube Diameter	Φ9.52	Φ9.52	Φ7	Φ7.94
Hole Space(mm)	25	25.4	20.5	22
Row Space(mm)	21.65	22	12.7	19.05
Tube Material	Copper, Aluminum	Copper, Aluminum	Copper, Aluminum	Copper, Aluminum
Type of Tube	Smooth Tube, Inner Grooved Tube	Smooth Tube, Inner Grooved Tube	Smooth Tube, Inner Grooved Tube	Smooth Tube, Inner Grooved Tube
Fin Surface	Louver Fin, Corrugated Fin	Flat Fin, Louver Fin, Corrugated Fin	Flat Fin, Louver Fin	Louver Fin
Fin Type	Hydrophilic Foil, Bare Foil, Copper Foil	Hydrophilic Foil, Bare Foil	Hydrophilic Foil, Bare Foil, Golden Foil	Hydrophilic Foil, Bare Foil, Golden Foil
Fin Thickness(mm)	0.095~0.2	0.095~0.2	0.095~0.2	0.095~0.2
Fin Space(mm)	1.4~2.3	1.4~2.3	1.1~1.8	1.4~2.0
